The Epson SureColor S40600 64" Eco-Solvent Printer is a professional roll-to-roll wide-format printer designed for signage, vehicle graphics, banners, decals, stickers, and other commercial display graphics.

The S40600 uses Epson's PrecisionCore TFP printhead technology and UltraChrome GS3 solvent ink in a four-color CMYK configuration. It supports media up to 64 inches wide and provides a maximum printable area of 63.6 inches. Epson positions the S40600 as an affordable 64-inch production printer for signage and display applications.

The printer offers production speeds of up to 215 sq ft/hr for banner media and 170 sq ft/hr for vinyl, with maximum draft speeds reaching up to 610 sq ft/hr, depending on print mode and media.

Product Specifications

• Brand: Epson
• Model: SureColor S40600
• Product Type: Wide-Format Eco-Solvent Printer
• Printer Configuration: Roll-to-Roll, Print Only
• Printing Technology: Advanced PrecisionCore TFP Print Head
• Printhead: 8-Channel, Drop-on-Demand Inkjet Printhead
• Ink Technology: Epson UltraChrome GS3 Solvent Ink
• Ink Configuration: CMYK
• Ink Capacity: 700 mL per color
• Maximum Media Width: 64" (1,626 mm)
• Maximum Printable Width: 63.6"
• Minimum Media Width: 12"
• Maximum Print Resolution: 1,440 × 1,440 dpi
• Minimum Ink Droplet Size: 4.2 picoliters
• Nozzle Configuration: 720 nozzles per color
• Draft Print Speed: Up to 610 sq ft/hr
• Production Speed – Banner: Up to 215 sq ft/hr
• Production Speed – Vinyl: Up to 170 sq ft/hr
• Quality Speed – Banner: Up to 170 sq ft/hr
• Quality Speed – Vinyl: Up to 140 sq ft/hr
• Maximum Roll Diameter: 9.84" (250 mm)
• Maximum Roll Weight: 95 lbs (43.1 kg)
• Supported Roll Core: 2" / 3"
• Interface: Hi-Speed USB 2.0 / Gigabit Ethernet
• Operating Temperature: 50–95°F (10–35°C)
• Operating Humidity: 20–80% RH
• Recommended Humidity: 40–60% RH
• Dimensions: 103" W × 34" D × 53" H
• Dimensions: 2,616 × 609 × 1,346 mm
• Weight: 615 lbs (278 kg)
• Power Supply: AC 100–120 V / 200–240 V
• Power Consumption: Approx. 650 W or less during operation
• Standby with Heaters On: Approx. 520 W
• Standby with Heaters Off: Approx. 30 W or less
• Sleep Mode: Less than 3.5 W

Ink System

The Epson SureColor S40600 uses:

Epson UltraChrome GS3 Solvent Ink

• Black
• Cyan
• Magenta
• Yellow

The standard ink supply is 700 mL per color. Epson specifies that the S40600 is designed for Epson ink cartridges.

Key Features

• 64" wide-format printing
• Roll-to-roll production workflow
• Epson PrecisionCore TFP printhead
• CMYK UltraChrome GS3 solvent ink
• Up to 1,440 × 1,440 dpi resolution
• Up to 610 sq ft/hr draft speed
• Up to 215 sq ft/hr banner production speed
• Up to 170 sq ft/hr vinyl production speed
• 63.6" maximum printable width
• 700 mL ink cartridges
• Gigabit Ethernet connectivity
• Designed for signage and display graphics
• Compatible with professional RIP workflows

Main Applications

• Signage
• Banners
• Vehicle Graphics
• Vehicle Wraps
• Stickers
• Decals
• Labels
• Posters
• Window Graphics
• Outdoor Advertising
• Promotional Graphics
• Retail Graphics
• Display Graphics
• Commercial Sign Production
